APEC FF100 NAIL-STRIP STANDING SEAM

Panel Features

• Panel Type

  Standing Seam SnapLock 16″

• Panel Seam

  1.0″ 22 GA – 24 GA Min

• Panel Width

  Smooth / Embossed Optional

• Seam Height

  None 3/12 Plywood

Notes:

• With this 24 GA, 16″ wide panel, you may opt to use heavier gauge coil and narrower width panels.
  Fastener spacing will not change.
• This panel uses a 20″ coil. Maximum width coil of 24″.
• This panel uses 4-1/16″ of material to form the panel.
• If you take the square footage of the roof and multiply that by 1.25, the total will be the amount coil needed to manufacture the panels.
• This panel is NOT approved for Weathertight Warranties.
